Description
Product Specifications
- 220 channels (Trimble BD970 board) or 120 channels (NovAtel 628 Board) dual frequency for GPS, GLONASS, GALILEO, SBAS and BEIDOU
- Satellite Signals: GPS: L1 C/A, L2E, L2C, L5 ,GLONASS: L1C/A, L1P, L2C/A (M only), L2P ,
- Satellite Signals: BEIDOU: B1 / B2, Galileo: L1BOC, E5A, E5B, E5AltBOC , QZSS: L1 C/A, L1 SAIF, L2C, L5 ,SBAS: L1 C/A, L5
- SBAS 0.5 m
- DGPS Accuracy: 0.25 m +1 ppm
- RTK Horizontal Accuracy: 0.008 m + 1 ppm
- RTK Vertical Accuracy: 0.015 m + 1 ppm
- Static Horizontal Accuracy: 2.5 mm + 0.5 ppm
- Static Vertical Accuracy: 5 mm + 0.5 ppm
- Internal Radio Frequency: 410 ~ 470 MHz & Output Power of 1W
- GSM/GPRS Modem: Telit HE910-D UMTS / HSPA+ / GSM / GPRS / EDGE (supporting NTRIP)
- Selectable Data Output:1 Hz, 2Hz, 5 Hz, 10 Hz, 20 Hz, 50 Hz
Product Description
- With advanced features for greater GNSS surveying efficiency
- Base/Rover switchable with internal radio modem
- 4 GB Internal data storage
- Various LED status indicators
- 2 Hot-swap batteries. Compatible with external power source using power cable (optional)
- Dust & water protection IP67
- New 3.5G GSM module for better performance
- Rugged shape and robust styling with rubber
- Equipped with TILT sensor that works as an electric bubble (G5Tt & G5Nt only)
- WiFi for direct communication with web browser for e.g. downloading data, firmware upgrades and communication between receiver and controller
