Description
Specification
| Height | Electronic Measurement | 0.7mm |
| Optical Measurement | 1.5mm | |
| Distance Measurement | Accuracy | D≤10m:10mm;D>10m:D*0.001 |
| Range | 1.8m – 110m | |
| Electronic Measurement | Resolution Height Measurement | 0.01mm/0.1mm/1mm |
| Resolution Distance Measuremen | 0.001m | |
| Measure Time | Less than 2.5 sec | |
| Telescope | Magnification | 32× |
| Field of view | 1º20′ | |
| Multiple constant | 100 | |
| Additive constant | 0 | |
| Compensator | Compensation range | ±15′ |
| Accuracy | 0.3″ | |
| Circular level sensitivity | 8’/2mm | |
| Size | L×B×H | 235mmx240mmX200mm |
| Weight | 3.1kg | |
| Power Supply | Voltage | 3400mAh, 7.4V |
| Operating Time | 20 hours | |
| Environmental | Operating Temperature | -20℃~+50℃ |
| Dust and water proof | IP65 |
Note: all information above is subject to change without any prior notice.
